New Product - Awaiting Price
(£
2931.60
incl VAT)
£ 2,443.00
excl VAT
Built on the same acclaimed hardware as its impressive predecessor, the BX420T flat head thermal transfer printer series delivers performance and efficiency at a lower cost driven by a powerful dual-core CPU and Toshiba’s advanced A-BRID operating system.
The A-BRID OS automatically detects print command languages and optimises output, including direct printing of pdf documents without needing any processing on a computer.
More than just a printer, the BX420T can be a stand-alone hub with direct connection of peripherals such as a barcode scanner, keyboard or scales.
With customisation and cloud connectivity the BX420T can be tailored to suit the production workflow and managed remotely, perfect for multi-site operations.
BX430T Printer
Quick Start Guide
Print Method: Thermal Transfer / Direct Thermal
Printhead: Flat head
Resolution:
HS02: 600 dpi (24 dots/mm)
Max. Print Speed: 6 ips (152 mm/s)
Max. Print Width: 107 mm
User Interface: Full colour LCD screen, 2 LED indicators, 11 physical buttons
Media:
Alignment: Centred (with auto-width detection)
Backing Paper Width: 25-110 mm
Inner Media Core Diameter: 76.2 mm
Outer Media Roll Diameter: max 200 m
Media Format: Roll, fanfold
Near End Detection: Adjustable, e.g. 10% remaining
Ribbon:
Ribbon width: max. 112 mm
Ribbon Core Size: 25.7 mm (±0.2 mm)
Max Ribbon Length: 300 m
Max ribbon roll diameter: 70 mm
Near End Detection: 30 or 70 m selectable
Dimensions (W x D x H):
278 mm x 460 mm x 310 mm
Weight:
17 kg
Toshiba TEC BX430T 600dpi, 4" Next Gen Thermal Transfer Industrial Printer, A-BRID Platform
BX430T-HS02-QM-S
