What is the maximum RFID read rate?
The TC22R can read up to 1,300 RFID tags per second.
What is the maximum RFID read distance?
The integrated RFID antenna provides a nominal read range of up to 12.2 metres (40 ft) under optimal conditions. Actual performance will vary depending on tag type, orientation, environmental conditions and interference.
How much does the TC22R weigh?
The Zebra TC22R weighs 569 g (20.07 oz) including its integrated RFID reader.
What display does the TC22R use?
The device features a 6.0-inch Full HD+ touchscreen with a resolution of 1080 x 2160 pixels, LED backlighting and brightness of up to 450 nits. The display supports operation with bare fingers or light gloves.
What are the operating temperature limits?
The TC22R is designed to operate between -10°C and +50°C (14°F to 122°F).
What is the storage temperature range?
The device can be stored between -40°C and +70°C (-40°F to 158°F).
What IP rating does the TC22R have?
The TC22R is sealed to IP65, providing protection against dust ingress and low-pressure water jets.
What is the drop specification?
The TC22R is rated for multiple drops from 1.5 m (5 ft) onto concrete, helping to reduce downtime and repair costs in demanding environments.
How much memory and storage does the TC22R have?
The standard configuration includes 6 GB RAM and 64 GB Flash storage.
What processor does the TC22R use?
The TC22R is powered by a Qualcomm 5430 Hexa-Core 2.1 GHz processor.
What operating system does it run?
The TC22R runs Android, with support for Zebra's extended Android upgrade lifecycle.
What wireless connectivity options are available?
The device supports:
- Wi-Fi 6E (802.11ax)
- Bluetooth 5.2
- NFC
- USB-C 3.1 connectivity
What barcode scanner is included?
The TC22R includes Zebra's SE4710 1D/2D scan engine, allowing RFID and barcode capture from a single device.
What battery does the TC22R use?
The unit features a user-removable 7,000 mAh PowerPrecision+ lithium-ion battery.
Does the TC22R include cameras?
Yes. The device includes:
- 16 MP rear camera
- 5 MP front camera
What RFID standards are supported?
The TC22R supports:
- EPC Class 1 Gen 2
- EPC Gen 2 V2 (UHF RFID)
